Description
Overview
The ASCO 8316G14 is a pilot-operated, 3-way normally closed solenoid valve engineered for demanding air and water applications in commercial and industrial HVAC systems. Built around a robust brass body with an NBR (Buna-N) seal and brass disc, this valve delivers reliable, leak-free shut-off and directional flow control across a wide operating pressure range.
Key Features
- 3-way, normally closed (NC) valve configuration for positive shut-off when de-energized
- Pilot-operated design handles high-pressure differentials efficiently
- 3/8″ NPT port connection for easy inline installation
- 120VAC coil voltage — compatible with standard commercial control circuits
- 2.5 Cv flow coefficient for optimized flow performance
- Operating pressure range: 10–250 PSI
- Brass body construction for corrosion resistance and long service life
- NBR (Nitrile) seal material — suitable for air and water media
- Brass disc for durable seating and reliable cycle life
- NEMA 4X enclosure rating — protected against dust, splashing water, and corrosion; suitable for indoor and outdoor use
Specifications
- SKU: 8316G14
- Brand: ASCO
- Valve Type: 3-Way, Normally Closed
- Operation: Pilot Operated
- Port Size: 3/8″ NPT
- Coil Voltage: 120VAC
- Flow Coefficient (Cv): 2.5
- Operating Pressure Range: 10–250 PSI
- Media: Air and Water
- Body Material: Brass
- Seal Material: NBR (Nitrile Buna-N)
- Disc Material: Brass
- Enclosure Rating: NEMA 4X
Applications
- HVAC air and water control systems
- Pneumatic control circuits
- Industrial process automation
- Fluid handling and distribution systems
- Outdoor or wash-down environments requiring NEMA 4X protection
