Description
The Copeland 90-165 is a 3-pole, 30-amp contactor rated for 208/240V applications, designed for switching three-phase and multi-pole single-phase loads in commercial HVAC equipment, electric heating systems, and mechanical power distribution applications where higher pole count and dual voltage compatibility are required. The 3-pole configuration allows simultaneous switching of all three load conductors in a single contactor operation, making it well suited for three-phase compressor and fan motor loads found in light commercial rooftop units, package systems, and air handling equipment, as well as multi-stage electric heat sequencer applications in electric furnaces and air handlers. The 30-amp contact rating per pole accommodates the inrush and continuous running current demands of the compressor, fan, and electric heat loads common to these equipment classes. Dual voltage rating at 208/240V provides compatibility across both nominal voltage supplies encountered in commercial building electrical systems, eliminating the need to stock separate contactors for each voltage tier. As an OEM-quality Emerson White-Rodgers replacement, the 90-165 is a direct-fit service component for preventive maintenance inspections and diagnostic service calls on commercial HVAC and electric heating equipment where contactor wear, contact pitting, or coil failure has been identified.
Key Features
- 3-pole configuration switches all three load conductors simultaneously for three-phase and multi-pole applications
- 30-amp contact rating per pole accommodates compressor, fan motor, and electric heat inrush and running current demands
- 208/240V dual voltage rating provides compatibility across both nominal voltage supplies in commercial building electrical systems
- Suited for light commercial rooftop units, package systems, air handlers, and electric furnace applications
- Eliminates need to stock separate contactors for 208V and 240V supply configurations
- Heavy-duty contact construction engineered for reliable performance under repeated high-current switching cycles
- OEM-quality Emerson White-Rodgers replacement for field service and preventive maintenance applications
- Direct substitution design supports efficient swap-out during diagnostic service calls on commercial HVAC and electric heating equipment
