Honeywell T822K1042 Econostat Low Temp Heat Only Mechanical Thermostat

Description

Honeywell Econostat Low Temp Heat Only Mechanical Thermostat – T822K1042 – perfect for low temp appications like garages.

This simple mechanical thermostat offers a setpoint range of 35 F to 85 F

Features:

• Vented cover for improved temperature sensing.
• Setting lever and thermometer scale on thermostat cover.
• Mounts directly on the wall or on vertical outlet box.
• Integrated thermometer and setting scale.
• Mercury Free

Specifications:

• Application Heat Only
• Mounting Vertical
• Color Premier White®
• Stages 1 Heat
• Terminal Designations R, W
• Switch Positions (System) HEAT-OFF
• Switch Type Precision Snap Action
• Switching Action SPST
• Accuracy (F) ±2 F
• Accuracy (C) ±1 C
• Dimensions (in.) 4 3/4 in. high x 2 7/8 in. wide x 1 3/8 in. deep
• Dimensions (mm) 121 mm high x 73 mm wide x 35 mm deep
• Setting Temperature Range (F) 35 F to 85 F
• Electrical Ratings 20 to 30 Vac
• Heat Current 0.02 A to 1.0 A running
• Sensor Element Bimetal
• Voltage 20 to 30 Vac

Features and Benefits

• 1H/0C low heat applications
• Vented cover for improved temperature sensing
• Setting lever and thermometer scale on thermostat cover
• Integrated thermometer and setting scale
• Mounts directly on the wall or on vertical outlet box
• 2-year warranty
