Description
The Honeywell MP909E1380 pneumatic actuator delivers proportional modulation for HVAC dampers and mixing boxes with precision and dependability. Operated by pneumatic pressure in the 9–13 psi range, it includes an automatic spring return for reliable fail-safe performance. A robust 3-inch stroke, rolling diaphragm mechanism, and corrosion-resistant materials make it a solid choice for long-term HVAC control.
Specifications:
- Air Connections: 1/8″ NPT, Dual Barbed fitting for 5/32″ or 1/4″ O.D. tubing
- Product Type: Actuator
- Actuator Type: Pneumatic
- Temperature Range (F): -28°F to 160°F
- Actuator Spring Range: 9 to 13 psi
- Fail Safe Mode: Spring Return
- Stroke: 3″
- Max Pressure (PSI): 30
- Features: External trunnion mounting bracket
