Description
The Honeywell/Resideo S8600H3002 is a proven intermittent pilot ignition control module designed for use with both natural and LP gas systems. It delivers controlled spark ignition, flame detection, and full safety shutoff. With a single ignition trial and 90‑second lockout, it ensures secure operation and requires manual reset upon lockout.
Specifications:
- Ignition System Type: Intermittent Pilot
- Ignition Sequence: Lockout
- Typical Gas Control: VR8204, VR8304
- Type of Gas: Natural or LP
- Flame Sense: Single Rod
- Ignition Source: Internal high voltage spark generator
- PrePurge: None
- Ignition Trials To Lockout: 1
- Lockout Timing: 90 seconds
- Ignition Trial Time (sec): 90 sec
- Maximum Valve Load @ 24 Vac (Amps): 1A Pilot, 1A Main @ 24Vac
- Typical Ignition Hardware: Q345, Q3451
- Dimensions: 3 15/16 in. high x 5 7/16 in. wide x 2 5/8 in. deep
- Electrical Ratings: 24 Vac
- Frequency: 60 Hz
- Approvals, CSA: Design Certified
- Flame Failure Response Time (sec): 2 seconds maximum
