Description
Strengthen the control and reliability of your HVAC systems with the Honeywell VGF21EP30 — a robust, pressure-balanced 3-inch globe valve designed for precise 2-position or modulating control of steam, hot water, and chilled water with glycol solutions up to 50%. Engineered for performance and durability, this valve excels in demanding environments.
Features:
- ANSI Class 125 cast iron bodies with flanged end connections
- Equal percentage and linear flow characteristics
- Face-to-face flange dimensions per ANSI/ISA S75.03 standard
- Sizes from 2-1/2 to 6 in.
- Stainless steel trim standard for long life span
- Differential pressure of 175 psi, ANSI Class IV leakage
- Steam inlet pressure up to 125 psig and 353 F maximum temperature
- Self-adjusting packing
- Accurate positioning with equal percentage and linear flow characteristics to ensure precise temperature control
- Universal bonnet for direct-coupled electric and pneumatic actuators for easy mounting, or linkage coupled Modutrol? Motors and MN/MS Series direct coupled actuators
- Not suitable for combustible gasses
