Description
The Johnson Controls VG7441LT+3008E is a factory-assembled, 2-way normally closed control valve paired with a spring-return exposed pneumatic actuator — engineered for reliable flow control in commercial HVAC hydronic systems. The cast bronze body with brass trim delivers long-lasting corrosion resistance, while the equal percentage flow characteristic ensures precise, stable modulation across a wide range of operating conditions.
Key Features
- 2-way, normally closed (NC) valve configuration
- 3/4″ NPT end connections for straightforward pipe installation
- 7.3 Cv flow coefficient — equal percentage flow characteristic
- Cast bronze body with brass trim for durability and corrosion resistance
- 9–13 PSI spring range for reliable spring-return actuation
- Spring-return, exposed pneumatic actuator (Model 3008E) for fail-safe operation
- Factory-assembled valve and actuator combination for simplified installation
Valve Specifications
- Valve Model: VG7441LT
- Actuator Model: 3008E
- Configuration: 2-Way, Normally Closed
- Connection Size: 3/4″ NPT
- Flow Coefficient (Cv): 7.3
- Flow Characteristic: Equal Percentage
- Body Material: Cast Bronze
- Trim Material: Brass
Actuator Specifications
- Actuator Type: Spring-Return Exposed Pneumatic
- Spring Range: 9–13 PSI
- Action: Spring Return (Fail-Safe Closed)
Typical Applications
- Commercial HVAC hydronic heating and cooling systems
- Air handling unit coil control
- Fan coil unit water flow regulation
- Building automation and pneumatic control systems
Why Choose the Johnson Controls VG7441LT+3008E?
This pre-assembled valve and actuator combination from Johnson Controls simplifies specification and installation, reducing field assembly time and ensuring factory-verified compatibility between the valve body and pneumatic actuator. The spring-return design provides a reliable fail-safe closed position upon loss of pneumatic signal, making it an ideal choice for safety-critical HVAC applications.
