Description
The Reznor 101902 is a heavy-duty, two-way normally open actuated ball valve assembly engineered for demanding commercial and industrial HVAC and hydronic applications. Built around a forged brass body with stainless steel trim, this valve delivers reliable equal-percentage flow control with a 74 Cv flow coefficient through a full 3-inch port. The spring-return actuator ensures fail-safe normally open operation on a loss of power, while the 120VAC two-position electric actuator provides precise on/off control. Dual 2-SPDT auxiliary switches provide end-of-travel feedback for integration with building automation or control panels.
Key Features
- Two-way, normally open (N.O.) configuration for fail-safe operation
- 3-inch pipe size with ASME Class 150 flanged end connections
- 74 Cv flow coefficient with equal-percentage flow characteristic
- 120VAC two-position spring-return actuator
- Forged brass body for corrosion resistance and long service life
- Stainless steel trim for enhanced durability in hydronic and steam applications
- Spring-return mechanism ensures fail-safe normally open position on power loss
- Two built-in 2-SPDT auxiliary switches for end-of-travel position feedback
Specifications
- SKU: 101902
- Brand: Reznor
- Valve Type: 2-Way Ball Valve Assembly
- Valve Action: Normally Open (N.O.)
- Pipe Size: 3 inch
- End Connection: ASME Class 150 Flange
- Flow Coefficient (Cv): 74
- Flow Characteristic: Equal Percentage
- Body Material: Forged Brass
- Trim Material: Stainless Steel
- Actuator Voltage: 120VAC
- Actuator Type: Spring Return, Two-Position
- Auxiliary Switches: 2 x SPDT
Applications
- Commercial and industrial HVAC hydronic systems
- Hot water and chilled water coil control
- Building automation and energy management systems
- Heating and cooling plant piping requiring flanged connections
