Description
Streamline motor status detection and control with the Veris H930, a compact split‑core current switch featuring an integrated 24 VAC/DC SPST command relay—no external power needed.
Specifications:
- Application: Building Automation Systems
- Current Measurement Range: 1.5 – 200 A
- Electrical Wiring Size: 24 – 14 AWG (0.2 – 2.1 mm²)
- Measurement Type: AC Current
- Monitored Frequency Range: 50 – 60 Hz
- Monitored Wire Size: 0.8″ (21 mm)
- Mounting: Split Core
- Operating Humidity: 10 – 90% RH, non-condensing
- Operating Temperature: 5 – 140 °F (-15 – 60 °C)
- Output Specifications: N.O. 1 A @ 250 VAC
- Outputs: Switch output | Relay
- Product Certification: UL | CE
- Range: HX30 Series
- Relay Coil Voltage: 24 VAC/DC
- Relay Contact Ratings: Resistive: 10 A @ 250 VAC | Resistive: 10 A @ 30 VDC | Inductive: 5 A @ 250 VAC | Inductive: 5 A @ 30 VDC
- Relay Poles/Throw: SPST
- Setpoint: Fixed
