Description
The Belimo SGVL+SVB24-SR is a factory-assembled combination of a Belimo SGVL globe valve body paired with the SVB24-SR actuator — delivering a complete, ready-to-install valve and actuator solution engineered for demanding commercial HVAC hydronic applications.
Product Overview
Designed for precise modulating control of heating and cooling coils, heat exchangers, and other hydronic systems, this assembly combines Belimo’s proven globe valve technology with a powerful non-spring-return (NSR) actuator. The 2-10 VDC control signal enables smooth, proportional flow regulation, making it ideal for building automation and energy management systems.
Key Features
- Factory-matched globe valve and actuator combination for simplified installation
- 24V AC/DC power supply for broad compatibility with BAS and control systems
- 337 lbf (1,500 N) actuator force for reliable valve authority in high-pressure hydronic systems
- Non-spring-return (NSR) operation — holds last position on power loss
- 2-10 VDC modulating control signal for precise proportional flow control
- Compact, direct-coupled design eliminates the need for linkages or adapters
- Suitable for hot water, chilled water, and condenser water applications
- Belimo’s industry-leading quality and reliability for long service life
Actuator Specifications
- Model: SVB24-SR
- Supply Voltage: 24V AC/DC
- Control Signal: 2-10 VDC (modulating)
- Actuator Force: 337 lbf (approx. 1,500 N)
- Operation Type: Non-Spring-Return (NSR)
- Fail Mode: Holds last position on power loss
Valve Specifications
- Valve Body: Belimo SGVL series globe valve
- Application: Hydronic heating and cooling systems
- Design: Direct-coupled to SVB24-SR actuator
Typical Applications
- Commercial HVAC air handling units (AHUs)
- Fan coil units and unit ventilators
- Chilled water and hot water coil control
- Heat exchanger flow regulation
- Building automation and energy management systems
